CEMB K9 DIGITAL WHEEL BALANCER

SKU: K9
Manufacturer part number: K9
Free shipping
Quick overview The CEMB K9 Digital Wheel Balancer balances steel and light alloy wheels of cars, light trucks, motorcycles & scooters (with optional adaptors).
$3,399.00


CEMB heavy duty wheel balancer for medium to large size car automotive garages, car dealerships, and tire shops. This machine comes fully assembled.



CEMB K9 DIGITAL WHEEL BALANCER FEATURES

Universal space saving wheel balancer with excellent technical specs combining a sturdy structure with attractive & modern design
Balances steel & light alloy wheels of cars, light trucks, motorcycles & scooters (with optional adaptors)
Automatic Distance & Diameter Entry (2D)
Foot pedal brake for easy weight placement
Standard Quick Nut Mounting
Self-Diagnosis and Self-Calibration
Menus for quick selection of the following:
    inches to millimeters
    unbalanced thresholds 0.1 or 0.25 ounces (1 or 5g)
Direct selection ounces/grams
Optimization program for compensation of rim and tire unbalance
"Static" program--plus 4 ALU programs for PAX, light alloy or special shaped rims
One Button Split & Hidden Weight Program
Direct weight location program (no repositioning of stick-on weights)
10-Compartment Weight Tray






SPECIFICATIONS



Power Supply: 110VAC, 50/60 Hz, 1 ph
Shaft Size: 40mm
Balancing Speed: < 100 rpm
Balancing Accuracy: < 0.1 oz
Rim Diameter Capacity: 10" - 30"
Rim Width Capacity: 1.5" - 20"
Max. Wheel Weight: 165 lbs
Max Tire Diameter: 42" (36" with spalsh guard)
Operating Temperature: °F 32-113 (°C 0-45)
Average Cycle Time: 4-6 seconds
Gross Ship. Weight: 260 lbs






STANDARD ACCESSORIES



Quick Nut: Quick release wingnut
Cup & Pressure Ring: Reverse mounting cup with no mar-ring + Pressure ring
Cones: 3 cones covering hole sizes 1.69” (43mm) to 4.33” (110mm)
Shaft: 40mm threaded shaft
Caliper: Rim width gauge for measuring wheel width
Weight Pliers: Can be used as balanced weight hammer, cutting pliers for trimming wheel weights, and puller to remove the old wheel weights
Test Weight
Allen Wrench: 8mm allen wrench to mount the 40mm threaded shaft
Storage: 3 pegs for adaptors storage






OPTIONAL ACCESSORIES



Wheel Guardvirtual direct drive wheel balancer

WBL81 - Pneumatic lift for wheel balancers

Motorcycle Adaptor - Universal motorcycle and scooter adaptor kit with 15mm arbor, cones and spacers for bearing type wheels and single side arm (flange) type wheels (Wheel guard required)



SRU - Universal stud adaptor (for wheels with 3-4-5-6 holes, 75-210mm bolt pattern)

UH20/2 -CEMB PATENT* Universal bolt pattern adaptor (for wheels 3-4-5 holes or without center hole)

WD + DC: WD wheel support spacer for very wide wheels + DC spring pusher bush

RL Cup + No Mar Ring: Large diameter plastic cup for alloy rims protection (8.11"/206mm for alloy rims, includes no-mar ring)

SR USA: Stud adapter for rim protection and high precision (for lug centric wheels) for standard locking

2P Truck Cone Kit: 2 piece truck cone kit for light truck wheels for hole from 3.82" (97mm) to 7.09" (180mm)

3P Truck Cone Kit: 2 piece truck cone kit + GG spacer ring to fit Ford F-350, 450 and 550

8.5" Super Cone: Cone for GMC 6500 series & International using 19.5" rims (must be used with 3 Piece Truck Cone Kit)






CEMB K9 DIGITAL WHEEL BALANCER MANUAL



CEMB K9 DIGITAL WHEEL BALANCER DRAWING



WHAT TYPE OF WHEEL BALANCER IS RIGHT FOR YOU? CHECK OUT OUR WHEEL BALANCER GUIDE.



WHO IS CEMB? LEARN ABOUT ONE OF THE LEADING MANUFACTURERS OF GARAGE WHEEL SERVICE EQUIPMENT IN THE WORLD!

Write your own review
  • Only registered users can write reviews
  • Bad
  • Excellent
Product description


CEMB heavy duty wheel balancer for medium to large size car automotive garages, car dealerships, and tire shops. This machine comes fully assembled.



CEMB K9 DIGITAL WHEEL BALANCER FEATURES

Universal space saving wheel balancer with excellent technical specs combining a sturdy structure with attractive & modern design
Balances steel & light alloy wheels of cars, light trucks, motorcycles & scooters (with optional adaptors)
Automatic Distance & Diameter Entry (2D)
Foot pedal brake for easy weight placement
Standard Quick Nut Mounting
Self-Diagnosis and Self-Calibration
Menus for quick selection of the following:
    inches to millimeters
    unbalanced thresholds 0.1 or 0.25 ounces (1 or 5g)
Direct selection ounces/grams
Optimization program for compensation of rim and tire unbalance
"Static" program--plus 4 ALU programs for PAX, light alloy or special shaped rims
One Button Split & Hidden Weight Program
Direct weight location program (no repositioning of stick-on weights)
10-Compartment Weight Tray






SPECIFICATIONS



Power Supply: 110VAC, 50/60 Hz, 1 ph
Shaft Size: 40mm
Balancing Speed: < 100 rpm
Balancing Accuracy: < 0.1 oz
Rim Diameter Capacity: 10" - 30"
Rim Width Capacity: 1.5" - 20"
Max. Wheel Weight: 165 lbs
Max Tire Diameter: 42" (36" with spalsh guard)
Operating Temperature: °F 32-113 (°C 0-45)
Average Cycle Time: 4-6 seconds
Gross Ship. Weight: 260 lbs






STANDARD ACCESSORIES



Quick Nut: Quick release wingnut
Cup & Pressure Ring: Reverse mounting cup with no mar-ring + Pressure ring
Cones: 3 cones covering hole sizes 1.69” (43mm) to 4.33” (110mm)
Shaft: 40mm threaded shaft
Caliper: Rim width gauge for measuring wheel width
Weight Pliers: Can be used as balanced weight hammer, cutting pliers for trimming wheel weights, and puller to remove the old wheel weights
Test Weight
Allen Wrench: 8mm allen wrench to mount the 40mm threaded shaft
Storage: 3 pegs for adaptors storage






OPTIONAL ACCESSORIES



Wheel Guardvirtual direct drive wheel balancer

WBL81 - Pneumatic lift for wheel balancers

Motorcycle Adaptor - Universal motorcycle and scooter adaptor kit with 15mm arbor, cones and spacers for bearing type wheels and single side arm (flange) type wheels (Wheel guard required)



SRU - Universal stud adaptor (for wheels with 3-4-5-6 holes, 75-210mm bolt pattern)

UH20/2 -CEMB PATENT* Universal bolt pattern adaptor (for wheels 3-4-5 holes or without center hole)

WD + DC: WD wheel support spacer for very wide wheels + DC spring pusher bush

RL Cup + No Mar Ring: Large diameter plastic cup for alloy rims protection (8.11"/206mm for alloy rims, includes no-mar ring)

SR USA: Stud adapter for rim protection and high precision (for lug centric wheels) for standard locking

2P Truck Cone Kit: 2 piece truck cone kit for light truck wheels for hole from 3.82" (97mm) to 7.09" (180mm)

3P Truck Cone Kit: 2 piece truck cone kit + GG spacer ring to fit Ford F-350, 450 and 550

8.5" Super Cone: Cone for GMC 6500 series & International using 19.5" rims (must be used with 3 Piece Truck Cone Kit)






CEMB K9 DIGITAL WHEEL BALANCER MANUAL



CEMB K9 DIGITAL WHEEL BALANCER DRAWING



WHAT TYPE OF WHEEL BALANCER IS RIGHT FOR YOU? CHECK OUT OUR WHEEL BALANCER GUIDE.



WHO IS CEMB? LEARN ABOUT ONE OF THE LEADING MANUFACTURERS OF GARAGE WHEEL SERVICE EQUIPMENT IN THE WORLD!
