PHOENIX PWC2950 TIRE CHANGER

SKU: PWC2950
Manufacturer part number: PWC2950
Free shipping
Quick overview Phoenix PWC2950 Tire Changer has capabilities of accepting helper arm as an option.
$1,695.00
$1,250.00

PHOENIX TIRE CHANGER DEMO VIDEO




Tire Changing Machine Inside Gear

1-Year Parts Warranty

Phoenix manufactures quality wheel service equipment at affordable prices. Have a look inside (right) a Phoenix tire changer you will see components such as metal air valves rather than plastic, a bead breaker cylinder built to last with 5500 lbs of force, a motor and transmission that run smooth without vibration that transfer plenty of power to handle even larger wheels, such as Ford F350. Foot control pedals operate metal air control valves structured for long trouble-free operation, unlike many higher priced products that use plastic valving but charge a premium price, perform no better, and do not last. Comparing Phoenix equipment with the big names you will learn Phoenix offers the same quality at a lower price (no big food chain to feed). We also offer better service; when you call, we answer. You won’t need to leave a message or pay ridiculous prices for replacement parts.

The top of the tire machine uses a large turntable (26″ or 28″), thick and rugged to handle large wheels. Behind the wheel clamps there are air jets, the part of the bead blaster which assists in seating the bead for mounting tires. The air supply tank is housed in the upright tower, eliminating the need for an exterior tank. The adjustable air regulator and water trap is mounted beside the automatic oiler, which is necessary to keep the machine lubricated – where there is compressed air, there is often moisture. The oiler drips oil into the machine each time you use a foot pedal function, spreading lubricant throughout the system and limiting wear on parts. It is easy to fill: just spin off the reservoir, on and off in a minute. Strong large cylinders under the turntable move the rim clamps in and out and provide a solid grip on wheels. Of course, the steel duck head — which removes and installs the tire on the wheel — is lined with plastic inserts to protect against damage to wheels.

**Included as a standard piece is an all plastic duck head you can install when working with high end wheels which are fragile. Other brands charge for this as an option, usually $70-$100.

PHOENIX PWC2950 TIRE CHANGER FEATURES:


**Includes an all plastic duck head for installing when working with fragile, high end wheels --normally an option with other suppliers All metal air valving throughout machine
Now capable of accepting helper arm (optional)
Easy fill oiler, limits wear on internal parts
Air filter/quick drain water trap with adjustable regulator
Heavy duty no flex 28" turntable, 110 volt electric power for forward and reverse, air power for clamping
Self Centering Clamp with stepping function
Quick Inflation Device for tubeless tire (bead blaster)
Precise inflate / deflate air gauge and hose
Rubber Padded Mount/Demount Tool (duckhead)
Includes reservoir for rubber lubricant
Includes plastic protectors for turntable clamps
Optional adapter for motorcycle
Angle of duckhead can be adjusted






SPECIFICATIONS:

Power Supply: 110V
Motor Power: 1.5 Hp
Air Supply: 0.6 - 1.0 mpa
Rim Clamping Range: 12 - 26" outside 14" - 28" inside
Bead Breaker Force: 5500 lbs
Max Wheel Diameter: 43"
Max Wheel Width: 15"
Shipping Weight: 680 lbs

TIRE CHANGER WHEEL BALANCER CUSTOMER PHOTOS

Phoenix Tire Changers and Balancers Customer Photos

Write your own review
  • Only registered users can write reviews
  • Bad
  • Excellent
Existing reviews
Works great for Motorcycle Car and Truck Tires
The tire changer works great for Motorcycle, car and truck tires.

Very happy we chose this tire changer not only because of the cost but it does everything that we needed it for.
From: chrisparkersr | Date: 8/1/2014 5:03 AM
Was this review helpful? Yes No (0/1)
A LOT OF POWER
I like the machine, it has a lot of power, will serve me well in what I need to do.

Turntable has more spinning power than my old machine.

All the pedals are in a different location than my other one so have to get used to it. Blowing up the tire is slow.
The gauge where air is in the tire 0 – 280 lbs you are only using less than a quarter, would be better to go just to 100. Would be nice to have bigger numbers and tic marks on the gauge.
From: bbaroffio | Date: 9/15/2014 7:37 AM
Was this review helpful? Yes No (0/1)
COULDN'T BE HAPPIER
Bought 2 full motorcycle lift packages, A tire machine and a wheel balancer with all the motorcycle adapter and everything shipped super fast and works great, I couldnt be happier and everytime someone asks where I got my Equipment I proudly say www.nhproequip.com, ask for Clark Heintz, he is the man!!!
From: scorpionchoppersinc | Date: 9/21/2014 10:18 PM
Was this review helpful? Yes No (0/1)
Great value
I purchased this tire changer for our shop to change motorcycle and car tires. This machine works great for both applications. It is a great value. Clark is great to deal with and I will be purchasing more equipment from him in the future.

Mel Minnick
Parker Motorsports
From: mm.autoland | Date: 11/5/2014 4:49 AM
Was this review helpful? Yes No (0/1)
just what I needed
Tire machine and rack are just what I needed. Imageautostyling thanks you for the good service and equipment.

-Kevin R, Image Auto Styling
Lake Saint Louis, Missouri
From: kevin | Date: 5/16/2017 8:35 AM
Was this review helpful? Yes No (0/0)
Product description

PHOENIX PWC2950 TIRE CHANGER FEATURES:


**Includes an all plastic duck head for installing when working with fragile, high end wheels --normally an option with other suppliers All metal air valving throughout machine
Now capable of accepting helper arm (optional)
Easy fill oiler, limits wear on internal parts
Air filter/quick drain water trap with adjustable regulator
Heavy duty no flex 28" turntable, 110 volt electric power for forward and reverse, air power for clamping
Self Centering Clamp with stepping function
Quick Inflation Device for tubeless tire (bead blaster)
Precise inflate / deflate air gauge and hose
Rubber Padded Mount/Demount Tool (duckhead)
Includes reservoir for rubber lubricant
Includes plastic protectors for turntable clamps
Optional adapter for motorcycle
Angle of duckhead can be adjusted






SPECIFICATIONS:

Power Supply: 110V
Motor Power: 1.5 Hp
Air Supply: 0.6 - 1.0 mpa
Rim Clamping Range: 12 - 26" outside 14" - 28" inside
Bead Breaker Force: 5500 lbs
Max Wheel Diameter: 43"
Max Wheel Width: 15"
Shipping Weight: 680 lbs
